FRP cable trays: technical data sheet

What we make, in the sizes and materials we offer. Anything outside these ranges we make to your drawing.

FRP cable trays — technical data
Type	Perforated and ladder type FRP cable trays, with FRP covers and fittings
Widths	Perforated 50–300 mm; ladder 150–1000 mm
Thickness	3–6 mm
Lengths	3000 mm ± 10 mm
Material	FRP — flame retardant, antistatic, UV-resistant, isophthalic polyester resin Glass content — more than 55% by weight Process — pultrusion on automated machines
Ladder side rails	Pultruded FRP channel, 150 mm high, 4 mm minimum thickness; FRP square-tube rungs at 300 mm
Fire retardancy	IS 6746; oxygen index 30 minimum to ASTM D2863
Load test	As per NEMA FG 1, at a 1.5 m support span
Hardware	FRP couplers (straight, variable-angle and horizontal hinged) with SS 304 bolts
Bends	90° and 45°, 300 mm radius

Specification clauses for your BOQ

For consultants: copy a clause into your BOQ or technical specification, then adjust sizes and quantities to your schedule. Words in [brackets] are alternatives.

FRP trays — corrosive areas

Chemical, fertiliser, effluent, coastal and offshore areas

1. Cable trays in corrosive areas shall be FRP, perforated [ladder] type, manufactured by pultrusion from flame-retardant, antistatic, UV-resistant isophthalic polyester resin with glass content above 55% by weight.
2. Trays shall be flame retardant to IS 6746 with an oxygen index of not less than 30 to ASTM D2863; type test reports shall be submitted.
3. Thickness shall be 3 mm minimum for perforated trays up to 300 mm wide [4 mm for wider trays]; ladder side rails shall be pultruded FRP channels 150 mm high, 4 mm minimum.
4. Trays shall be supplied in 3000 mm lengths, with width and height as per the schedule.
5. Couplers shall be FRP (straight, variable-angle and hinged) with SS 304 nuts and bolts.
6. Load test shall be as per NEMA FG 1 at the scheduled support span.
7. Make: Pioneer Cable Trays or approved equivalent.

Pune-Based Manufacturer & Exporter: High-Quality Cable Trays | Perforated Cable Trays, Ladder Cable Trays, Hot Dip Galvanized Cable Trays | Complete Cable Management Solutions with Bends, Reducers, Tees, Elbows, Couplers | 29 Years Industry Expertise

FRP perforated and ladder trays are essential components in various industrial and commercial settings, offering robust cable management solutions. They are designed to support and organize electrical and data cables, ensuring safety and efficiency.

Specifications and Features:

Material: FRP is a composite material made of a polymer matrix reinforced with fibers (typically glass fibers). Provides high strength, durability, and corrosion resistance.
Corrosion Resistance: Highly resistant to chemical corrosion. Suitable for harsh environments where metal trays deteriorate quickly.
Lightweight: Significantly lighter than steel trays. Facilitates easier installation and reduces structural load.
Non-Conductive: Electrically non-conductive, minimizing electrical hazards. Eliminates the need for grounding.
High Strength-to-Weight Ratio: Excellent mechanical strength. Capable of supporting heavy cable loads while remaining lightweight.
UV Resistance: Formulated with UV inhibitors for prolonged sunlight exposure. Suitable for outdoor applications.
Perforated vs. Ladder Design: Perforated Trays: Feature holes or slots throughout the base, providing ventilation and drainage. Ladder Trays: Consist of two longitudinal side rails connected by transverse support members (rungs), offering maximum ventilation and cable access.
Fire Retardancy: Can be made with fire retardant resins.
Low Maintenance: Corrosion resistance and durability lead to minimal maintenance.
Applications: • Chemical and Petrochemical Plants: Exposure to corrosive chemicals. • Wastewater Treatment Facilities: Resistant to moisture and chemicals. vOffshore Platforms: Protection against saltwater corrosion. • Food and Beverage Industry: Ensures hygiene and corrosion resistance. • Telecommunications: Organizes and protects data cables. • Power Plants: Manages cables in high-voltage environments. • Commercial Buildings: Used in data centers and electrical rooms. • Infrastructure Projects: Ideal for bridges, tunnels, and outdoor applications.
Available Dimensions: Will be listed in a table format as required.

Description	FRP Perforated CT	FRP Ladder Type CT
Thickness	3-6mm	3-6mm
Length	3 Meters	3 Meters
Width	50 - 300 MM	150 - 1000 MM
Rung Construction	NA	FRP Square Tube
Rung Spacing	NA	300 MM
Coupler Plates	GRP FRP with SS Bolts	GRP FRP with SS Bolts
Angle of Bends	90° - 45°	90° - 45°
Radius of Bends	300 MM	300 MM
Fire Retardant	As per IS 6746	As per IS 6746

Questions buyers ask

Straight answers from our engineers. Ask us anything else on WhatsApp or by mail.

Home About Us Products Perforated Cable Trays Ladder Type Cable Trays Wire Mesh Type Cable Trays Trunking / Box Type Cable Trays Raceways Cable Ducts FRP Perforated / Ladder Trays Export — NEMA VE 1 Cable Trays IEC 61537:2023 Cable Trays Contact Us Enquiry Blogs Sitemap

What are Pioneer FRP cable trays and why are they used?

FRP (Fiberglass Reinforced Plastic) cable trays supplied by Pioneer are non-metallic, highly durable cable management systems. They are specifically engineered to replace traditional steel trays in environments subjected to extreme chemical exposure and severe corrosive elements.

What are the main industrial advantages of using FRP instead of galvanized steel?

The primary advantages of Pioneer FRP cable trays are their absolute immunity to rust and chemical corrosion, their non-conductive (electrically safe) properties, and their exceptionally lightweight structure, which significantly reduces installation time and structural load compared to steel.

Does Pioneer supply FRP trays in both perforated and ladder configurations?

Yes, Pioneer supplies FRP cable trays in both solid-bottom perforated designs (ideal for supporting flexible control and instrumentation cables) and heavy-duty ladder configurations (designed for maximum heat dissipation around large high-voltage power lines).

Which industries primarily utilize Pioneer FRP perforated and ladder trays?

Pioneer FRP trays are heavily specified by procurement teams in highly corrosive B2B sectors. Key installations include marine and offshore oil rigs, chemical and petrochemical processing plants, fertilizer factories, coastal infrastructure, and wastewater treatment facilities.

Do Pioneer FRP cable trays meet industrial fire safety and outdoor weather standards?

Yes, Pioneer formulates its FRP cable trays using advanced UV inhibitors to prevent degradation from direct sunlight in outdoor applications. Additionally, they are manufactured using specialized fire-retardant resins to meet strict industrial fire safety and self-extinguishing compliance standards.
